ZTE Blade V9 (zte-p450f10)

From postmarketOS Wiki
This device has been archived. This means that it no longer appears in pmbootstrap and is likely broken.
It can still be selected in pmbootstrap init by typing in the vendor and codename, but you will have to build the kernel package manually.
ZTE Blade V9
ZTE Blade V9 P450F10
ZTE Blade V9 P450F10
Manufacturer ZTE
Name Blade V9
Codename zte-p450f10
Released 2018
Type handset
Hardware
Chipset Qualcomm Snapdragon 450 (SDM450)
CPU Octa-core 1.8 GHz Cortex-A53
GPU Adreno 506
Display 1080 x 2160 S-IPS LCD
Storage 32GB/64GB
Memory 3G/4G
Architecture aarch64
Software
Original software
The software and version the device was shipped with.
 Android 8.1
Extended version
The most recent supported version from the manufacturer.
 Android
postmarketOS
Category archived
Mainline
Instead of a Linux kernel fork, it is possible to run (Close to) Mainline.
 no
pmOS kernel
The kernel version that runs on the device's port.
 3.18.71
Device package device-zte-p450f10
Kernel package linux-zte-p450f10
Features
Flashing
Whether it is possible to flash the device with pmbootstrap flasher.
Untested
USB Networking
After connecting the device with USB to your PC, you can connect to it via telnet (initramfs) or SSH (booted system).
Works
Battery
Whether charging and battery level reporting work.
Untested
Screen
Whether the display works; ideally with sleep mode and brightness control.
Broken
Touchscreen
Untested
Multimedia
3D Acceleration
Untested
Audio
Audio playback, microphone, headset and buttons.
Untested
Camera
Untested
Connectivity
WiFi
Untested
Bluetooth
Untested
GPS
Untested
NFC
Near Field Communication
Untested
Modem
Calls
Untested
SMS
Untested
Mobile data
Untested
Miscellaneous
FDE
Full disk encryption and unlocking with unl0kr.
Untested
USB OTG
USB On-The-Go or USB-C Role switching.
Untested
Sensors
Accelerometer
Handles automatic screen rotation in many interfaces.
Untested

Contributors

Installation

First of all you need to unlock the bootloader.

Instruction how to do this is are here.

pmbootstrap build --strict --force --arch aarch64 linux-zte-p450f10 device-zte-p450f10 && pmbootstrap install && pmbootstrap export

Via EDL mode, download boot.img and rootfs.

Docker support

Edit the kernel config:

CONFIG_CGROUP_DEVICE=y
CONFIG_MEMCG=y
CONFIG_MEMCG_SWAP=y
CONFIG_MEMCG_SWAP_ENABLED=y
CONFIG_MEMCG_KMEM=y
CONFIG_CGROUP_PERF=y
CONFIG_OVERLAY_FS=y

Connect to device via ssh:

git clone https://github.com/tianon/cgroupfs-mount
cd cgroupfs-mount && ./cgroupfs-mount

Edit /etc/docker/daemon.json:

{
 "storage-driver": "overlay"
}

sudo dockerd --iptables=false


Users owning this device

See also
